Two Dimensional Compact Multi Beam Radar 3d Phased Array Radar

Products

Navigation Deception Equipment

Two Dimensional Compact Multi Beam Radar 3d Phased Array Radar

MOQ:	1
Price:	Negotiable
Delivery Period:	30days
Payment Method:	D/P,T/T,Western Union
Supply Capacity:	20set/month

Detail Information

Product Description

Detail Information

Place of Origin

Chengdu

Brand Name

Model Number

LY-Ku-3D-I

Scanning Range Pitch:

0°-40°

Operating Temperature:

-20 To 50 Degrees Celsius

Antenna Rotation:

360 Degrees

Power Consumption:

Less Than 5 KW

Data Processing:

Real-time

Scanning Range:

Azimuth：0°-360°，Pitch：0°-40°

Transmit Power:

Antenna Speed:

Maximum 90 °/s

Transmitter Power:

1-10 KW

Range:

Up To 100 Km

Scanning Range Azimuth:

Target Radial Velocity:

0.8m/s-40m/s

Resolution:

Antenna Type:

Parabolic

Polarization:

Dual Polarization

Minimum Detection Range:

Operating Frequency Band:

X Band

Range Resolution:

1-10 M

Antenna Diameter:

1-5 M

Blind Range:

Scan Mode:

Sector Scan

Operating Altitude:

0-10 Km

Receiver Sensitivity:

-120 DBm

Pulse Width:

1-10 μs

Pulse Repetition Frequency:

100-1000 Hz

Highlight:

Two Dimensional Multi Beam Radar

Two Dimensional 3d Phased Array Radar

Compact Multi Beam Radar

Product Description

Advanced Technology and Compact Design The Perfect Radar Jamming Solution

Product Overview

The LY-Ku-3D-I Two-Dimensional Phased Array Radar adopts a phased array system with TWS (Track While Scan) and TAS (Track And Scan) modes for target detection and tracking. TWS meets general wide-area surveillance requirements, while TAS enables high-data-rate continuous tracking of critical targets. It is designed to search, detect, and track low-altitude, slow-moving small drones (e.g., UAVs), measure target parameters, and provide data to other

Key Features

Advanced System Design: Software-defined, reconfigurable architecture.
Flexible Scanning: Customizable scanning zones with high time-resource efficiency.
Dual Modes:
- Single-array phased scanning + full-space mechanical scanning.
- Four-array phased scanning for full-space coverage.
Compact & Reliable: High integration, low cost, lightweight, and robust performance.
High-Priority Tracking: Enhanced data rate for critical targets.

Technical Specifications

Category	Parameter	Details
Operating Frequency		Ku-band
Detection Range	Target Capacity	200 targets
	Max Detection Distance	≥5 km (2D phased scan mode, RCS=0.01m², extendable)
	Min Detection Distance	≤200 m
	Altitude Coverage	≥1000 m (for targets with 2m² RCS)
	Azimuth Range	Phased scan: -45° to +45°; Mechanical scan: 0° to 360°
	Elevation Range	-10° to +50°
Detection Accuracy	Distance (RMS)	≤20 m
	Azimuth (RMS)	≤0.6°
	Altitude (RMS)	≤0.9°
Detection Capability	Distance Resolution	15 m
	Azimuth Resolution	≤4°
	Altitude Resolution	≤6°
	Data Rate	6s (TWS normal mode), 2s (TWS small-target mode), 0.5s (TAS mode)
	Detection Probability	0.8
	False Alarm Rate	10⁻⁶
	Track Initiation Time	≤3 frames
Data Processing	Processing Delay	≤1s (from target detection to data output)
Operational Performance	Power Supply	AC (220V±10%, 50Hz±5%) or portable generator
	Power Consumption	≤650 W
	MTBF (Reliability)	≥1000 hours
	MTTR (Maintainability)	≤30 minutes
	BIT Fault Detection Rate	≥95%
Environmental Adaptability	Operating Temperature	-35℃ to +50℃ (outdoor equipment)
	Storage Temperature	-45℃ to +65℃
	Humidity Resistance	98% RH (at 35℃ for outdoor equipment)
	Protection Level	IP-rated three-proof capabilities (waterproof, dustproof, corrosion-resistant)
Mobility & Deployment	Transport & Installation	Compatible with standard vehicles, modular design for flexible assembly,
		elevator/hoisting installation for rooftop deployment
