X-Band 3D AESA Air Defense Radar | 25km Detection Range & 200-Target Tracking with Integrated C-UAS Countermeasures

Products

Navigation Deception Equipment

X-Band 3D AESA Air Defense Radar | 25km Detection Range & 200-Target Tracking with Integrated C-UAS Countermeasures

MOQ:	1
Price:	Negotiable
Delivery Period:	30
Payment Method:	L/C, T/T
Supply Capacity:	10sets per Month

Detail Information

Product Description

Detail Information

Place of Origin

Chengdu

Brand Name

HYH

Operating Temperature:

-40°C To 60°C

Transmit Power:

256W

Blind Range:

240m

Pitch Coverage:

0°-30°

Frequency Range:

2-18 GHz

Technical System:

DBF

Scan Rate:

Up To 30 Degrees Per Microsecond

Range Resolution:

Less Than 1 Meter

Data Processing:

Real-time

Material:

Aluminum Copper

Operating Frequency Band:

X Band

Size:

≤700*290*450(mm)

Radar Wave Band:

Antenna Speed:

≤10rpm

Target Radial Velocity:

0.8m/s-20m/s

Minimum Detection Range:

10 M

Range Resolution:

1-10 M

Scanning Range Pitch:

0°-40°

Antenna Diameter:

1-5 M

Blind Range:

180m

Scan Mode:

Sector Scan

Antenna Rotation:

360 Degrees

Scanning Range Azimuth:

360°

Operating Altitude:

0-10 Km

Receiver Sensitivity:

-120 DBm

Pulse Width:

1-10 μs

Transmitter Power:

1-10 KW

Pulse Repetition Frequency:

100-1000 Hz

Range:

Up To 100 Km

Highlight:

3d air defense radar

3d air surveillance radar

dbf air defense radar

Product Description

System Overview

Our X-Band 3D Air Defense System combines cutting-edge 2D electronic scanning radar with full-spectrum counter-UAV jamming, delivering comprehensive protection against aerial threats. Featuring ±30° elevation/±15.5° azimuth electronic scanning + 360° mechanical rotation, this military-grade solution detects stealth targets (0.01m² RCS) at 8km while neutralizing hostile drones within 2km in 3 seconds.

![System Operation: Radar scanning airspace while jamming UAV control signals]

Key Advantages

✅ 25km Extended Reach - Detects conventional aircraft (1m² RCS) at maximum range
✅ Cluster Defense - Tracks 200+ targets simultaneously with 0.8m/s velocity resolution
✅ Battlefield Tough - IP67 rating & -40°C~+70°C operation range
✅ Rapid Deployment - 55kg radar head with <10rpm mechanical scan speed
✅ Energy Efficient - 256W transmit power reduces operational costs

Core Technologies

Radar Innovations

![Array Icon] Advanced Beam Steering	![Target Icon] Smart Tracking	![Chip Icon] Solid-State Reliability
- Hybrid electronic/mechanical scanning	- Real-time Doppler analysis	- GaN-based TR modules
- 15m range resolution	- 20m positioning accuracy	- 100,000+ hour MTBF
- Adaptive clutter rejection algorithms	- Threat priority sorting	- Modular field-replaceable units

Jammer Capabilities

![Signal Icon] Spectrum Dominance	![Shield Icon] Instant Neutralization	![Gear Icon] Fail-Safe Design
- 20MHz-6GHz broadband coverage	- 3s automatic threat response	- Worm gear self-locking mechanism
- 8 programmable focus bands	- 960W smart power allocation	- Military-grade embedded controller
- 3x directional + 1x omni antennas	- GPS/GLONASS spoofing capability	- Dual cooling system

Technical Specifications

Radar Performance

Detection	Scanning	Physical
- 0.01m² RCS @8km	- ±15.5° electronic azimuth	- 686×411×145mm size
- 0.8-100m/s velocity range	- ±30° electronic elevation	- 55kg weight
- 200 concurrent tracks	- 360° mechanical rotation	- 24/48V DC input

Jammer Parameters

Coverage	Precision	Durability
- 2km effective radius	- ≤0.8° bearing accuracy	- IP67 environmental proof
- 60+ simultaneous jams	- 3s reaction time	- MIL-STD-810 vibration
- 960W peak power	- 8-band selective jamming	- 50G shock resistance

Operational Scenarios

![Border Icon] Territorial Defense

Detect cruise missiles & stealth drones
Coastal radar cross-section optimization

![Base Icon] Military Installation Protection

24/7 airspace monitoring for forward bases
Integrated with SAM systems

![City Icon] Urban Security

Low-probability-of-intercept (LPI) mode
Crowded spectrum environment operation

![Factory Icon] Critical Infrastructure

Protect nuclear plants/power grids
EMP-hardened design

Performance Benchmark

Capability	Conventional Systems	Our System
Detection Range	15km (1m² RCS)	25km (1m² RCS)
Power Consumption	500W+	256W (49% reduction)
Target Capacity	80 tracks	200+ tracks
Deployment Time	4-6 hours	<2 hours
Maintenance Cost	$12k/year	$6.8k/year

Certifications

MIL-STD-461F (EMC)
IP67 Dust/Waterproof
CE/FCC Part 15 Compliance
RoHS 3 Directive
