Intelligent Phased Array Radar Systems Multi Spectral Tracking Electro Optical System

Product Overview

The HYH-Ku07A and HYH-D6 system is specifically designed for low-altitude and maritime target monitoring, integrating Ku-band phased array radar with intelligent multi-spectral electro-optical tracking technology. This system provides precise, all-weather detection of dynamic targets such as UAVs, bionic aircraft, unmanned boats, and more. It is ideal for security, border defense, and critical infrastructure protection in complex environments.

Core Components

HYH-Ku07A One-Dimensional Three-Coordinate Phased Array Radar

• Frequency Performance: Ku-band AESA (Active Electronically Scanned Array) technology ensures high detection accuracy and robust anti-jamming capability.
• Scanning Mode: 360° mechanical scanning in azimuth + phase scanning in elevation for complete, no-blind spot coverage.
• Environmental Adaptability: Modular, solid-state design with adjustable pitch angle, enabling deployment in various terrains like mountainous and coastal areas.
• Reliability: Military-grade protection (windproof, corrosion-resistant, waterproof), with stable operation in temperatures from -40°C to 70°C.

HYH-D6 Intelligent Multi-Spectral Tracking System

• Multi-Spectral Fusion: Combines uncooled infrared thermal imager, visible light camera, and laser rangefinder for seamless day-and-night monitoring.
• Intelligent Algorithms: Supports automatic multi-target locking, trajectory prediction, and threat level assessment.
• Covert Detection: Passive thermal imaging technology penetrates haze, is immune to strong light interference, and resistant to electromagnetic jamming.
• Quick Response: High-precision turntable (0.01° positioning accuracy) combined with vehicle shock-absorbing design for instant target lock during movement.

System Advantages

• Precise Target Recognition: Anti-clutter technology effectively filters out false alarms from birds, weather balloons, and other non-threatening objects.
• Multi-Target Tracking: Capable of simultaneously tracking 50+ dynamic targets in complex, noisy environments.
• Long-Range Detection:
  • Radar detection range of up to 15 km (for targets with RCS ≥ 0.01㎡).
  • Visible light observation range of up to 5 km, thermal imaging up to 3 km (human-shaped targets).
• Intelligent Linkage: Automatically networks radar, electro-optical, and jamming systems for real-time target feedback to command centers.
• Laser Axis Micro-Adjustment: Electrically-controlled laser axis fine-tuning, allowing calibration without disassembly, reducing maintenance costs.
• Robust Durability:
  • IP67 protection rating ensures resistance to 8-level winds and acid rain.
  • Built-in intelligent temperature control ensures reliable operation in extreme environments from -40°C to 70°C.

Typical Applications

• Critical Infrastructure Protection: Low-altitude intrusion warning for airports, nuclear power plants, and military bases.
• Border Surveillance: Detection and interception of unauthorized UAVs and unmanned boats crossing borders.
• Emergency Response: Tracking and locating chemical balloons, out-of-control model aircraft, and other potential hazards.
• Vehicle-mounted Deployment: Quick, flexible mobile surveillance and rapid setup for temporary defenses in under 5 minutes.

Optional Expansion: Supports integration with radio detection and full-spectrum jamming systems to create an integrated air-sea defense network.
